Aquatec Pressure Switch 40 psi shut off 3/8" tubing TSO 6800 8800 pump PSW-340
Aquatec Pressure Switch + Quick Connect Electrical Wire Plugs (made in USA) Brand: Aquatec (Genuine Aquatec products) Model: PSW-340 This pressure switch is used to control the on/off of the Aquatec booster pump 6800 series and 8800 series. Typical application is installed in a RO reverse osmosis water system. Instruction is included with the purchase. This pressure switch comes with quick connect wire plugs that connect quickly to Aquatec booster pump and Aquatec transformer. This switch has 3/8" inlet and outlet quick connect fitting. All you need to do is push in a 3/8" OD tubing into the inlet and outlet all the way in, the fitting will seal itself. To remove the tubing, you just need to push the plastic ring firmly agaist the fitting then you can pull out the tubing. Pressure Setting: It is pre-set at 40 psi cut-off pressure, but it is adjustable. The adjustable range is 30 to 60 psi Operation: When the pressure switch is connected to a Aquatec pump and Aquatec transformer, it will turn on the pump when pressure switch is sensing below 40 psi, then it will turn off the pump when the pressure is sensing 40 psi or above. We also carry many other variation of the Aquatec pressure switches. Aquatec # Preset cut-off Adjustable Range Inlet/Outlet eBay item # PSW-240 40 psi 30 to 60 psi 1/4" PSW-340 40 psi 30 to 60 psi 3/8" this listing PSW-260 60 psi 50 to 90 psi 1/4" PSW-360 60 psi 50 to 90 psi 3/8" PSW-280 80 psi 70 to 110 psi 1/4" PSW-380 80 psi 70 to 110 psi 3/8" PSW-2100 100 psi 90 to 150 psi 1/4" PSW-3100 100 psi 90 to 150 psi 3/8" Technical specification: Wetted Materials: Nylon, Santoprene, Nitrile Switch Rating: 250VAC, up to 15 amps, UL recognized NSF/FDA approved material Single pole, Double throw Normally Closed
Specifications
| Restocking Fee | 20% |
| Return Shipping Will Be Paid By | Buyer |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 14 Days |
| Refund Will Be Given As | Money Back |
| Model | ALL |
| Country/Region Of Manufacture | United States |
| Custom Bundle | Yes |
| Compatible Brand | ALL |
| Material | Plastic |
| Type | PRESSURE SWITCH |
| Compatible Model | ALL |
| Color | Black |
| MPN | Does Not Apply |
| Brand | AQUATEC |
| Suitable For | Commercial |
Aquatec Pressure Switch + Quick Connect Electrical Wire Plugs (made in USA) Brand: Aquatec (Genuine Aquatec products) Model: PSW-340 This pressure switch is used to control the on/off of the Aquatec booster pump 6800 series and 8800 series. Typical application is installed in a RO reverse osmosis water system. Instruction is included with the purchase. This pressure switch comes with quick connect wire plugs that connect quickly to Aquatec booster pump and Aquatec transformer. This switch has 3/8″ inlet and outlet quick connect fitting. All you need to do is push in a 3/8″ OD tubing into the inlet and outlet all the way in, the fitting will seal itself. To remove the tubing, you just need to push the plastic ring firmly agaist the fitting then you can pull out the tubing. Pressure Setting: It is pre-set at 40 psi cut-off pressure, but it is adjustable. The adjustable range is 30 to 60 psi Operation: When the pressure switch is connected to a Aquatec pump and Aquatec transformer, it will turn on the pump when pressure switch is sensing below 40 psi, then it will turn off the pump when the pressure is sensing 40 psi or above. We also carry many other variation of the Aquatec pressure switches. Aquatec # Preset cut-off Adjustable Range Inlet/Outlet eBay item # PSW-240 40 psi 30 to 60 psi 1/4″ PSW-340 40 psi 30 to 60 psi 3/8″ this listing PSW-260 60 psi 50 to 90 psi 1/4″ PSW-360 60 psi 50 to 90 psi 3/8″ PSW-280 80 psi 70 to 110 psi 1/4″ PSW-380 80 psi 70 to 110 psi 3/8″ PSW-2100 100 psi 90 to 150 psi 1/4″ PSW-3100 100 psi 90 to 150 psi 3/8″ Technical specification: Wetted Materials: Nylon, Santoprene, Nitrile Switch Rating: 250VAC, up to 15 amps, UL recognized NSF/FDA approved material Single pole, Double throw Normally Closed
